Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 2.94A 230VAC black/red WRAS type MAGNA3 100-60F (450)

Product number: 7039827
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 2.94A 230VAC black/red WRAS type MAGNA3 100-60F (450)
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 2.94A 230VAC black/red WRAS type MAGNA3 100-60F (450)
Grundfos Variable speed circulation pump cast iron DN100 flange 10bar 2.94A 230VAC black/red WRAS type MAGNA3 100-60F (450)
Select your item below or order directly via full product table
Power
MWC
All displayed prices are gross prices. Please log in or contact sales for custom pricing.
Price excl. VAT £3,112.20 / 1 pcs
£3,112.20 / pcs
Price incl. VAT £3,734.64 / 1 pcs
£3,734.64 / pcs
Available at supplier, please contact us - available on request, please contact sales team
pcs
Box qty:
1 pcs
MSQ:
1 pcs

Fast, free shipping on orders over £350*

Your trade partner in water technology

9.1/10 Read reviews

Frequently bought together

Jason Cap PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0707192
Jason Cap PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW

£1.32
Profec Sealing tape PTFE 12 mm white 10m
0070011
Profec Sealing tape PTFE 12 mm white 10m

£0.76
Profec Elbow 90° PVC-U 32 mm glue socket 16bar grey KIWA
0110108
Profec Elbow 90° PVC-U 32 mm glue socket 16bar grey KIWA

£0.84
Profec Wormdrive hose clip stainless steel 304 20 mm x 32 mm type W4 12 mm
0464483
Profec Wormdrive hose clip stainless steel 304 20 mm x 32 mm type W4 12 mm

£0.74
Greener choice Greener choice
Pressure pipe PE40 20 mm x 1,5 mm plain 4bar black 100m
0700003
Pressure pipe PE40 20 mm x 1,5 mm plain 4bar black 100m

£0.70
Pressure pipe PVC-U 63 mm x 2,4 mm glue socket x plain 10bar ISO-PN10 grey 5m
0309063
Pressure pipe PVC-U 63 mm x 2,4 mm glue socket x plain 10bar ISO-PN10 grey 5m

£2.37
Jason Elbow 90° PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0706525
Jason Elbow 90° PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW

£2.16
Profec Pipe clamp PP 20 mm black type 2
0110951
Profec Pipe clamp PP 20 mm black type 2

£0.49
Greener choice Greener choice
Pressure pipe PE 22 mm x 2.4 mm plain 6bar black 50m
0700578
Pressure pipe PE 22 mm x 2.4 mm plain 6bar black 50m

£0.81
Profec Hose tail adaptor brass 1/4" x 13 mm male thread x hose tail 30bar
0411804
Profec Hose tail adaptor brass 1/4" x 13 mm male thread x hose tail 30bar

£1.06

Technical details

  • Colour
    black/red
  • Maximum ambient temperature
    40 °C
  • Size
    DN100
  • Pressure
    10 bar
  • Type
    MAGNA3 100-60F (450)
  • Ampere
    2.94 A
  • Impellers
    1
  • Material impeller 1
    fibreglass-reinforced PES
  • Voltage
    230VAC
  • Connection
    flange
  • Minimum medium temperature (continuous)
    -10 °C
  • Frequency
    50 Hz
  • Approval
    WRAS
  • Minimum ambient temperature
    0 °C
  • Max. temperature
    110 °C
  • Pump body
    cast iron
  • Material
    cast iron
  • EAN
    4019305785600
  • Part number
    7039827
  • Manufacturer
    Grundfos

Variants

Product number:
Price
Box qty
MSQ
Stock
No variants found
Adjust or clear the selected filters to see available variants.
7039796
0.074 kW
4
£628.80
1
1
7039797
0.11 kW
6
£735.00
1
1
7039798
0.144 kW
8
£777.00
1
1
7039799
0.18 kW
10
£883.80
1
1
7039800
0.336 kW
12
£1,467.00
1
1
(2)
7039801
0.097 kW
4
£783.60
1
1
7039802
0.178 kW
6
£855.00
1
1
(1)
7039803
0.265 kW
8
£1,214.40
1
1
7039804
0.348 kW
10
£1,336.80
1
1
7039805
0.44 kW
12
£1,530.60
1
1
(1)
7039806
0.608 kW
15
£1,815.00
1
1
7039807
0.607 kW
18
£2,087.40
1
1
7039808
0.139 kW
4
£1,618.20
1
1
7039809
0.249 kW
6
£1,905.60
1
1
(1)
7039810
0.325 kW
8
£2,097.60
1
1
7039811
0.429 kW
10
£2,220.60
1
1
7039812
0.536 kW
12
£2,344.20
1
1
7039813
0.63 kW
15
£2,700.60
1
1
7039814
0.762 kW
18
£3,166.80
1
1
7039815
0.194 kW
6
£2,028.60
1
1
7039816
0.35 kW
6
£2,316.60
1
1
7039817
0.478 kW
8
£2,522.40
1
1
7039818
0.613 kW
10
£2,659.80
1
1
7039819
0.769 kW
12
£2,851.80
1
1
(1)
7039820
1.301 kW
15
£3,005.40
1
1
7039821
0.326 kW
4
£2,426.40
1
1
7039822
0.53 kW
6
£2,673.00
1
1
7039823
0.721 kW
8
£2,878.80
1
1
7039824
1.041 kW
10
£2,877.60
1
1
7039825
1.297 kW
12
£3,231.60
1
1
7039826
0.465 kW
4
£2,851.80
1
1
7039827
0.664 kW
6
£3,112.20
1
1
7039828
0.971 kW
8
£3,093.00
1
1
7039829
1.244 kW
10
£3,367.80
1
1
7039830
1.576 kW
12
£3,819.60
1
1
