DAB Submersible pump technopolymer 1" female thread 2,9A 230VAC black/green type Divertron X 650
Product information
Pumped liquid: clean, free of solids and abrasives, non-viscous, non-aggressive, and chemically neutral, with properties similar to water. Max. immersion depth: 12 metres. Pump also works when partially submerged.Built-in pressure switch, control circuit board sensor, non-return valve, with dry run protection.
Supplied with stainless steel suction filter or stainless steel connection fitting for use with suction kits, particularly suitable for tanks or cisterns with debris or dirt lying at the bottom. Installation: fixed or portable, vertical position.
| Material impeller 1 | technopolymer |
|---|---|
| IP value | IP68 |
| Shaft | stainless steel 416 |
| Size | 1" |
| Temperature range | 0 - 40°C |
| Cable length | 15 m |
| Connection | female thread |
| Impellers | 3 |
| Material | technopolymer |
| Max flow rate | 4.8 m³/h |
| Colour | black/green |
