Grundfos Multi-stage centrifugal pump stainless steel 1 1/4" 1A 400VAC type CRI 1S-13 A CA I V HQQV
Product number: 7039618
Manuals & drawings
Select your item below or order directly via
full product table
All displayed prices are gross prices. Please log in or contact sales for custom pricing.
Price excl. VAT
£1,785.12 / 1 pcs
£1,785.12 / pcs
Price incl. VAT
£2,142.14 / 1 pcs
£2,142.14 / pcs
Available at supplier, please contact us
- available on request, please contact sales team
Frequently bought together
0080196
0080706
0075083
0100724
0412032
7002773
0100303
0410784
0080934
Technical details
-
Motor RPM2770
-
Max flow rate1.1 m³/h
-
Maximum ambient temperature40 °C
-
TypeCRI 1S-13 A CA I V HQQV
-
Pump bodystainless steel 316
-
Impellers13
-
IP valueIP55
-
Materialstainless steel
-
Output Power0.5 HP
-
Ampere1 A
-
Shaftstainless steel 316
-
Temperature range-20°C - 90°C
-
Frequency50 Hz
-
Material impeller 1stainless steel 304
-
Voltage400VAC
-
Suction1 1/4 "
-
Size1 1/4"
-
EAN4019305783873
-
Part number7039618
-
ManufacturerGrundfos
Dimensions
-
Cb-150 mm
-
Cb-250 mm
-
H-1628 mm
-
L162 mm
-
W-1210 mm
-
ØDi-11 1/4 "
-
ØDi-135 mm
-
ØDi-235 mm
-
ØDi-21 1/4 "
Similar products
Product description
Grundfos CRI pumps are vertical, non-self-priming, multistage, in-line, centrifugal pumps for installation in pipe systems and mounting on a foundation, suitable for industrial applications. This design provides a more compact pump design and pipework. CR pumps are designed for a variety of applications ranging from the pumping of potable water to the pumping of chemicals. The pumps are therefore suitable for a wide range of pumping systems where the performance and material of the pump meet specific demands.
