Grundfos MAGNA3 40-180FN (250) Variable speed circulation pump stainless steel DN40 flange 10bar 2.68A 230VAC black/red WRAS

Product number: 7039851
Skip image gallery
Grundfos MAGNA3 40-180FN (250) Variable speed circulation pump stainless steel DN40 flange 10bar 2.68A 230VAC black/red WRAS
Grundfos MAGNA3 40-180FN (250) Variable speed circulation pump stainless steel DN40 flange 10bar 2.68A 230VAC black/red WRAS
Grundfos MAGNA3 40-180FN (250) Variable speed circulation pump stainless steel DN40 flange 10bar 2.68A 230VAC black/red WRAS
Select your item below or order directly via full product table
Type
Size
Max. head
All displayed prices are gross prices. Please log in or contact sales for custom pricing.
Price excl. VAT £3,357.89 / 1 pcs
£3,357.89 / pcs
Price incl. VAT £4,029.47 / 1 pcs
£4,029.47 / pcs
Out of stock, please contact us for availability
pcs
Box qty:
1 pcs
MSQ:
1 pcs

Fast, free shipping on orders over £450*

Your trade partner in water technology

9.1/10 Read reviews

Frequently bought together

Jason Cap PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0707192
Jason Cap PP 25 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW

£1.32
Profec Sealing tape PTFE 12 mm white 10m
0070011
Profec Sealing tape PTFE 12 mm white 10m

£0.86
Profec Elbow 90° PVC-U 32 mm glue socket 16bar grey KIWA
0110108
Profec Elbow 90° PVC-U 32 mm glue socket 16bar grey KIWA

£0.96
Profec Wormdrive hose clip stainless steel 304 20 mm x 32 mm type W4 12 mm
0464483
Profec Wormdrive hose clip stainless steel 304 20 mm x 32 mm type W4 12 mm

£0.80
Greener choice Greener choice
Pressure pipe PE40 20 mm x 1,5 mm plain 4bar black 100m
0700003
Pressure pipe PE40 20 mm x 1,5 mm plain 4bar black 100m

£0.83
Pressure pipe PVC-U 63 mm x 2,4 mm glue socket x plain 10bar ISO-PN10 grey 5m
0309063
Pressure pipe PVC-U 63 mm x 2,4 mm glue socket x plain 10bar ISO-PN10 grey 5m

£3.10
Profec Pipe clamp PP 20 mm black type 2
0110951
Profec Pipe clamp PP 20 mm black type 2

£0.49
Greener choice Greener choice
Pressure pipe PE 22 mm x 2.4 mm plain 6bar black 50m
0700578
Pressure pipe PE 22 mm x 2.4 mm plain 6bar black 50m

£0.89
Profec Nr. 310 Nut brass 3/8" female thread 30bar
0710406
Profec Nr. 310 Nut brass 3/8" female thread 30bar

£0.73
Jason Elbow 90° PP 20 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW
0706520
Jason Elbow 90° PP 20 mm compression 16bar black/blue DVGW/KIWA/WRAS/SVGW

£1.84

Technical details

  • Colour
    black/red
  • Maximum ambient temperature
    40 °C
  • Pump body
    stainless steel
  • Ampere
    2.68 A
  • Pressure
    10 bar
  • Impellers
    1
  • Material
    stainless steel
  • Material impeller 1
    fibreglass-reinforced PES
  • Voltage
    230VAC
  • Connection
    flange
  • Minimum medium temperature (continuous)
    -10 °C
  • Frequency
    50 Hz
  • Approval
    WRAS
  • Minimum ambient temperature
    0 °C
  • Max. temperature
    110 °C
  • EAN
    4019305785846
  • Part number
    7039851
  • Manufacturer
    Grundfos

Variants

Product number:
Price
Box qty
MSQ
Stock
No variants found
Adjust or clear the selected filters to see available variants.
7039840
MAGNA3 32-40FN (220)
DN32
4 m
£943.16
1
1
7039841
MAGNA3 32-60FN (220)
DN32
6 m
£1,102.11
1
1
7039842
MAGNA3 32-80FN (220)
DN32
8 m
£1,164.21
1
1
7039843
MAGNA3 32-100FN (220)
DN32
10 m
£1,325.26
1
1
7039844
MAGNA3 32-120FN (220)
DN32
12 m
£2,220.00
1
1
7039845
MAGNA3 40-40FN (220)
DN40
4 m
£1,174.74
1
1
7039846
MAGNA3 40-60FN (220)
DN40
6 m
£1,365.26
1
1
7039847
MAGNA3 40-80FN (220)
DN40
8 m
£2,198.95
1
1
7039848
MAGNA3 40-100FN (220)
DN40
10 m
£2,425.26
1
1
7039849
MAGNA3 40-120FN (250)
DN40
12 m
£2,672.63
1
1
7039850
MAGNA3 40-150FN (250)
DN40
15 m
£3,288.42
1
1
7039851
MAGNA3 40-180FN (250)
DN40
18 m
£3,357.89
1
1
7039852
MAGNA3 50-40FN (240)
DN50
4 m
£2,425.26
1
1
7039853
MAGNA3 50-60FN (240)
DN50
6 m
£2,856.84
1
1
7039854
MAGNA3 50-80FN (240)
DN50
8 m
£3,144.21
1
1
7039855
MAGNA3 50-100FN (280)
DN50
10 m
£3,329.47
1
1
7039856
MAGNA3 50-120FN (280)
DN50
12 m
£3,513.68
1
1
7039857
MAGNA3 50-150FN (280)
DN50
15 m
£4,048.42
1
1
7039858
MAGNA3 50-180FN (280)
DN50
18 m
£4,747.37
1
1
7039859
MAGNA3 65-40FN (340)
DN65
4 m
£3,042.11
1
1
7039860
MAGNA3 65-60FN (340)
DN65
6 m
£3,473.68
1
1
7039861
MAGNA3 65-80FN (340)
DN65
8 m
£3,782.11
1
1
7039862
MAGNA3 65-100FN (340)
DN65
10 m
£3,986.32
1
1
7039863
MAGNA3 65-120FN (340)
DN65
12 m
£4,274.74
1
1
7039864
MAGNA3 65-150FN (340)
DN65
15 m
£4,523.16
1
1
