Profec Swing check valve with lifting device ductile iron (GGG40) epoxy coating DN65 DIN flange 16bar DN65 blue PN10/16
Product information
The Swing check valve with lifting device, NBR flanged has an epoxy coated body and EPDM valve seal. It is mostly applied in the infrasturcture, municipal and construction industry and used for different machine building, watertreatment and agricultural projects.
The check valve contains a lifting device to release the ball if it gets stuck in a backflow position. It is available in wide range of DN sizes with a different flange connection and has a working pressure of 16 bar. The temperature is up to 80 degrees when steam is absent.
Profec is a professional brand, that is ideal for different water projects.
| Flange | PN10/16 |
|---|---|
| Material seal | NBR |
| Max. temp. | 100 °C |
| Temperature range | -20°C - 100°C |
| Connection | DIN flange |
| Material | ductile iron (GGG40) |
| Pressure | 16 bar |
| Surface treatment | epoxy coating |
