Grundfos Multi-stage centrifugal pump stainless steel 1 1/4" 2.5A 400VAC type CRI 1-17 A CA I V HQQV
Product information
Grundfos CRI pumps are vertical, non-self-priming, multistage, in-line, centrifugal pumps for installation in pipe systems and mounting on a foundation, suitable for industrial applications. This design provides a more compact pump design and pipework. CR pumps are designed for a variety of applications ranging from the pumping of potable water to the pumping of chemicals. The pumps are therefore suitable for a wide range of pumping systems where the performance and material of the pump meet specific demands.
| Material impeller 1 | stainless steel 304 |
|---|---|
| Maximum ambient temperature | 40 °C |
| Pump body | stainless steel 316 |
| Frequency | 50 Hz |
| IP value | IP55 |
| Shaft | stainless steel 316 |
| Size | 1 1/4" |
| Temperature range | -20°C - 90°C |
| Material | stainless steel |
| Max flow rate | 2.4 m³/h |
| Voltage | 400VAC |
